Product details of the solar camera trailer
Product Information
BIGLUX solar camera trailer is developed incorporating sophisticated technology and is made available to patrons at market leading prices. The product is tested on numerous quality parameters before supplying to patrons At present, solar camera trailer produced by BIGLUX INNOVATION LTD has already applied for national invention patents.
High definition camera installed on mobile trailer 6 to 9 meters mast with solar generator for security monitoring
Mobile surveillance trailer together with solar generator specification:
Base System
Brand: | BIGLUX |
Name: | Solar CCTV Trailer |
Model: | HS4602G-6M |
Material: | Steel Q235 |
Dimension: | Length×Width×Height |
Transport: | 1900×1500×1100 (mm) |
Operate: | 2900×2500×6200 (mm) |
Weight: | 800kg / 1764lb |
System Voltage: | DC24V |
Work Temperature: | -35℃~50℃ / -31℉~122℉ |
Solar System
Solar Panel: | 2 × 460W Monocrystalline Silicon |
Voltage: | DC42V |
Battery System
GEL: | 4 × 200Ah,Free-main,Deep-cycle |
Voltage: | DC12V |
Series & Parallel: | 2 in series, then parallel |
Power Capacity: | 9600W·h |
CCTV System
Box: | Square type |
Device: | PoE Switch |
Control System
Solar Controller: | MPPT,Hybrid,30A |
Efficiency: | 95%+ |
Detection & Protection: | Short-Circuit,Overload,High Voltage,High Temperature |
Whole Machine: | Battery Isolator,Device on-off |
Mast System
Body: | Aluminum Alloy 6063,Hard Anodized |
Type: | Round Telescopic |
Height: | 6m / 20ft |
Section: | 4 |
Spring Cable: | 2 × Cat6e + 2 × Power Supply |
Lifting Method: | Manual Winch |
Recommended Loading: | 5kg ~ 50kg / 11lb ~ 110lb |
Windproof: | 117km/h / 73mph |
Trailer System
Standard: | US / AU / EU |
Tow Hitch: | 50mm / 2'' Ball Type |
Trailer Light: | 7 Pin |
Outrigger: | 4 × Manual Galvanized |
Warranty: | 2 years |
Mobile surveillance trailer together with solar generator photo for reference
