Solar Panel:

6 x 460W MonoCrystalline solar panel

Controller:

60A MPPT Smart Epever Controller

Forklift Holes:

2 at back

Running Time:

7.68 hours for 3000W at 80% DOD

Input Plug:

1 AC input plug

Inquiry

Product details of the mobile solar power plant

Product Information

All materials of BIGLUX mobile solar power plant meet global standards. The product has passed out all conducted quality inspection and test. BIGLUX INNOVATION LTD always adheres to the principle of 'customer first'.

Mobile Off Grid Solar Generator

Solar power systems are not only sustainable, but also environmentally friendly. As long as there is sunlight, solar energy can be used. The inexhaustible supply is our evaluation of this energy and a yearning. With the gradual reduction of energy sources such as oil and natural gas, in order to avoid the crisis caused by its depletion, all countries are actively developing new energy, and electric energy is a more respected one. There are many ways to generate electricity. There are many ways to get electricity. Different regions use different clean energy sources to generate electricity according to different geographical characteristics, but solar energy is the most widely used. In addition to solar energy, the Biglux standalone off-grid solar trailer can replace traditional diesel generators because it is mounted on a very rugged trailer.

1 AC Input Plug 6 X 460W MonoCrystalline Solar Panel Mobile Solar Power Plant BIGLUX 6

1 AC Input Plug 6 X 460W MonoCrystalline Solar Panel Mobile Solar Power Plant BIGLUX 7

CONFIGURATIONS:

Solar Panel: 6* 460W, Monocrystalline Silicon (hydraulic lifting version available)

Battery: 12*200Ah,DC12V, 28800W·h lead acid batteries

Controller: 60A, 95% Efficiency smart MPPT controler

Inverter: 6kW/6kVA,50/60 Hz,Pure Sine Wave

Input Plug: 1 × AC240V / AC120V

Output Socket: 3 × AC240V / AC120V

Trailer: US/EU/AU Standard, Ball Hitch, single Axles, 4pcs Manual Outriggers, safety chains

Charging Time: 8.8 hours with good sunshine

Running Time: 38.4 hours for 600W, 11.5 hours for 2000W at 80% DOD

If you need to install lights or cameras, you can match an telescopic mast, for example, Steel Q235, Square Telescopic type, 6.5 m, 5 Sections, Electric Winch Lifting, recommend load: 5-70kg

1 AC Input Plug 6 X 460W MonoCrystalline Solar Panel Mobile Solar Power Plant BIGLUX 8

Doing assembly of the Mobile Off Grid Solar Generator in work shop with manual lifting telescopic mast

1 AC Input Plug 6 X 460W MonoCrystalline Solar Panel Mobile Solar Power Plant BIGLUX 9

Different single color available for your choice

Good qualit sliders:

1 AC Input Plug 6 X 460W MonoCrystalline Solar Panel Mobile Solar Power Plant BIGLUX 10

1 AC Input Plug 6 X 460W MonoCrystalline Solar Panel Mobile Solar Power Plant BIGLUX 11

1 AC Input Plug 6 X 460W MonoCrystalline Solar Panel Mobile Solar Power Plant BIGLUX 12

Mobile Off Grid Solar Generator mounted with led lights for lighting parking lot of Qatar 2022 FIFA World Cup

For the smart control system MPPT, there are some advantages:

High tracking efficiency ≥ 99.5%

Peak conversion efficiency of 98% and full load efficiency of 97%

Ultra-fast tracking speed

Accurately tracking and recognizing MPP among multiple wave crest

Reliable automatic PV current limiting function

Wide MPP operating voltage range

Die-cast aluminum design, ensuring excellent heat dissipation

Multiple load control modes: Manual Control, Light ON/OFF, Light on+timer and Time Control

Battery type selection: Sealed, Gel, Flooded and User(programmable)

Battery temperature compensation

Built-in running data and event logging

RS485 port with industrial standard MODBUS open architecture

Real-time data monitoring and parameters setting with MT50, APP or PC software available

Support firmware upgrade

If more details required, please feel free to contact Biglux.
